Description
Used for packing the beverage, beer, battery, hardware, electronic appliance and etc.
The shrinking machine is advanced overseas spiral blower technology, it’s use many famous factory’s fitting to achieves higher automation. Applicable to such shrinkable film as PVC, PP, POF, and PE, the shrink efficiency is special good. Combination unit – system runs on one circuit, Works with all shrink film, but specially Tunnel for non-PVC, polyolefin film, Temperature compensating solid state controllers. Works with all shrink film, Digital temperature controllers, Bottom heating Automatic cool down timer (increase lift span),Roller, wire mesh, options.
| MODEL | GSM- 6040 PE |
|
Machine Dimension
|
2900mm (L) x 1205mm (W) x 1670mm (H) |
|
Max. packaging dimension
|
1200mm (L) x 600mm (W) x 400mm (H) |
|
Sealing cutter / tunnel size
|
600mm (L) x 600mm (W) x 400mm (H) |
|
In-feed conveyor height
|
850mm ± 50 |
|
Sealing temperature
|
0-300°C |
|
Working efficiency
|
20-25 pcs per minute |
| Rated power | 18kw |
| Net weight | 550kg |
| Power supply | 3 Ø220v / 415V 50/60Hz |
| Film used | LDPE Shrinkable Film |
